Introduction

The Zeus Pro is offered in 336x256, or 640x512 pixel formats which are further enhanced by professional military grade 30mm, 50mm, 100mm Germanium (Ge) objective lenses creating a wide variety of optical magnifications and range performance capabilities.  It also has a unique dual battery option for the Zeus Pro Thermal Weapon Sight consisting either of four 3.0V DC CR123A batteries all oriented in the same direction to prevent confusion in replacement, or four 1.5V DC AA batteries pre-loaded in a cartridge. A single CR123A 3.0VDC battery can power the Zeus Pro for over one hour.

The Zeus Pro Thermal Weapon Sight is characterized by its simple and intuitive controls, functions, and features that are layered among direct button adjustments, direct combination button functions, and electronic menu selections. In an effort to better support the art of shooting, Armasight has included ballistic drop reticles, electronic compass and inclinometer in the Zeus Pro package for finer range estimation and target orientation. The Zeus Pro uses a 9-pin multi-pin connector to provide video-in imagery, where there may be a need for map or rangefinder display overlays, and external power access. In support of these capabilities, Armasight offers an optional laser range finder, external battery pack, multispectral laser and other accessories designed to attach on the MIL-STD-1913 rail of the Zeus Pro. Solid state technology reticle adjustments and software algorithms, combined with a complementary color reticle platform, ensures maximum reticle contrast, high level target accuracy, and boresight retention. This level of accuracy is translated into the tracking electronic zoom (e-zoom) function of the Zeus Pro thermal imaging weapon sights, which can be progressively increased from 1x to 2x to 4x and 8x without changing the point-of-aim to point of-impact relationship of the targeting reticle.

A five-button wireless remote switch is included to operate and modify the settings on the Zeus Pro to optimize the imagery for the viewed scene without having to remove your hands from the weapon. The Zeus Pro has Bluetooth© wireless capability and can directly interface with most smart phones with the potential for engaging a series of current and future applications.

Features

  • 24/7 Operation in presence of environmental obscurants (smoke, dust, haze,fog)
  • Superior engineering and design from inception to Armasight’s 20/50 standard
  • High Performance
  • Operates on CR123A or AA batteries
  • Reliable quick-release locking weapon mount
  • Objective Germanium Lens Options
  • TAU-2 17μm Pitch Thermal Sensor
  • SVGA 800x600 OLED Display
  • Long eye-relief eyepiece lens
  • Digital Compass
  • Digital Inclinometer
  • Battery Status Indicator
  • Multiple User Selectable Ballistic and Quick Acquisition Reticles
  • Selectable Reticle Color
  • Selectable Palettes: White Hot/ Black Hot/ Sepia/ OEM Custom/ Other Color Variants
  • Imaging Filter Algorithms:
    – Active Contrast Enhancement™ (ACE)
    – Second Generation Digital Detail Enhancement™ (DDE)
    – Smart Scene Optimization™ (SSO)
    – Information Based Histogram Equalization™ (IBHEQ)
    – Automatic Gain Control (AGC)
    – Silent Shutterless Non-uniformity Correction™ (SSN)
  • Wireless 5-button Remote
  • Tracking Digital e-Zoom: 2x / 4x / 8x (640x512 only)
  • Still Picture and Video Recording Capability (Mounted DVR Option)
